JVN UCP 211-32 Pillow Block Bearing (Shaft Dia 2 inch, 50.8mm) – Sealed Type with Rubber Seals | Z2V2+ Grade | HT200+ Grade Steel | G10 Balls | High RPM | For Conveyor Systems, Agricultural Machinery, Pumps, Gearboxes, Electric Motors, Industrial Fans, Grinders, Textile Machines, Material Handling Equipment, Compressors – 1PC
₹785.00 18% GST Included
High-performance JVN UCP 211-32 Pillow Block Bearing (Shaft Dia 2 inch, 50.8mm) – Sealed Type with Rubber Seals, Z2V2+ vibration rating, G10-grade balls, and HT200+ grade steel construction. Ideal for high-speed, light to moderate-load applications in conveyor systems, agricultural machinery, pumps, gearboxes, electric motors, industrial fans, grinders, textile machines, material handling equipment, and compressors.
120 in stock
Product Overview
JVN UCP 211-32 Pillow Block Bearing (Shaft Dia 2 inch, 50.8mm) – Sealed Type with Rubber Seals | Z2V2+ Grade | HT200+ Grade Steel | G10 Balls | High RPM | For Conveyor Systems, Agricultural Machinery, Pumps, Gearboxes, Electric Motors, Industrial Fans, Grinders, Textile Machines, Material Handling Equipment, Compressors – 1PC Experience unmatched precision and performance with the JVN UCP 211-32 Pillow Block Bearing, engineered for durability and low maintenance. Featuring Z2V2+ vibration standards, G10-grade balls, and 100% heat-treated chrome steel bearing with double rubber seals in a high-density HT200+ grade steel block, this sealed pillow block ensures smooth rotation, minimal noise, and extended lifespan with superior protection against dust and moisture. Ideal for high-speed, light to moderate-load applications in conveyor systems, agricultural machinery, pumps, gearboxes, electric motors, industrial fans, grinders, textile machines, material handling equipment, and compressors.🔧 Applications
- Conveyor Systems: Ensures reliable shaft support in medium-duty conveyor setups for material handling.
- Agricultural Machinery: Supports durable performance in equipment like tractors and harvesters.
- Pumps: Provides efficient operation in water and fluid pumps for industrial and agricultural use.
- Gearboxes: Enhances smooth rotation in gearbox assemblies under moderate loads.
- Electric Motors: Powers medium electric motors with precision in appliances and machinery.
- Industrial Fans: Ensures stable operation in large-scale ventilation and exhaust systems.
- Grinders: Supports high-speed performance in industrial grinding tools and equipment.
- Textile Machines: Delivers consistent performance in spinning and weaving machinery.
- Material Handling Equipment: Provides robust support in forklifts and other material handling systems.
- Compressors: Offers reliable performance in air and gas compression systems.
✅ Key Features
- Z2V2+ Quality: Meets stringent industrial standards for minimal vibration and noise.
- G10-Grade Balls: Ultra-precise balls reduce friction, ensuring low wear and long life.
- Sealed Type Design with Rubber Seals (2RS): Double rubber seals retain lubricant and protect against dust and moisture for low-maintenance operation.
- Precision-Ground Rings: Minimizes resistance for smoother motion at high RPMs.
- Durable Cage Material: Reinforced steel cage ensures stability under light to moderate loads.
- High-Speed Performance: Supports up to 4,600 RPM with grease lubrication, ideal for high-speed applications.
- Chrome Steel Construction for Bearing: 100% heat-treated chrome steel for superior strength and durability.
- HT200+ Grade Steel for Block: High-density housing for impact resistance and long-lasting performance.
- UCP 211-32 Pillow Block Dimensions: Shaft diameter 2 inch (50.8mm), total length 219mm, bolt center distance 171mm, height to center 57.2mm, overall height 130mm, width 65mm for precise fitment.
📏 Specifications (UCP 211-32 Pillow Block Bearing Size & Dimensions)
- Model: UCP 211-32 (Sealed Type with Rubber Seals)
- Shaft Diameter (d): 2 inch (50.8mm)
- Total Length (L): 219mm
- Bolt Center Distance (J): 171mm
- Height to Center (H): 57.2mm
- Overall Height (H2): 130mm
- Width (A): 65mm
- Base Thickness (S): 25mm
- Bolt Hole Diameter (N): 23mm
- Weight: 2.680 kg
- Block Material: HT200+ Grade Steel (High Density, Impact-Resistant)
- Bearing Material: 100% Heat-Treated Chrome Steel
- Ball Grade: G10 (High Precision)
- Cage Material: Reinforced Steel
- Dynamic Load Capacity: 43500N (9778 lbf)
- Static Load Capacity: 29300N (6587 lbf)
- Max RPM: 4,600 (grease lubrication)
- Temperature Range: -40°C to 120°C (-40°F to 248°F)
💡 Why Choose JVN UCP 211-32 Pillow Block Bearings?
The JVN UCP 211-32 Pillow Block Bearing is designed for professionals and hobbyists requiring high-performance, sealed pillow blocks with rubber seals for high-speed, light to moderate-load applications in dusty or moist environments. Its 2RS double rubber seal design retains lubricant and offers superior protection against contaminants, reducing maintenance needs, while the HT200+ grade steel block provides high density and impact resistance (resistant to breakage from drops or hits), and the chrome steel bearing with G10-grade balls guarantees durability and precision. Whether you’re building conveyor systems, agricultural machinery, or pumps, the JVN UCP 211-32 delivers reliable performance under high RPMs and demanding conditions.🛠️ Compatibility
- SolidWorks & CAD Design: Perfect for engineers needing precise radial pillow block bearing UCP 211-32 dimensions for modeling.
- Industry-Standard Compatibility: Compliance with industry standards like ISO.
- Light to Moderate-Duty Applications: Outperforms generic pillow blocks in high-speed, sealed environments with light to moderate loads.
🛒 Order Now
Get the JVN UCP 211-32 Pillow Block Bearing for your next project and experience unmatched quality and performance. Ideal for conveyor systems, agricultural machinery, pumps, gearboxes, electric motors, industrial fans, grinders, textile machines, material handling equipment, and compressors. Order today for fast shipping and reliable support!Weight | 2.935 kg |
---|---|
Dimensions | 220 × 62 × 127 mm |
Shaft Diameter (d) | 2 inch, 50.8mm |
Total Length (L) | 219mm, 21.9cm |
Bolt Center Distance (J) | 171mm, 17.1cm |
Height to Center (H) | 63.5mm, 6.35cm |
Overall Height (H2) | 126mm, 12.6cm |
Width (A) | 60mm, 6cm |
Base Thickness (H1) | 23mm, 2.3cm |
Bolt Hole Diameter (N) | 20mm, 2cm |
